TRANSMISSION
KUKJE MACHINERY CO., LTD.
91
5. CHECKING, DISASSEMBLING AND SERVICING
< 2
nd
Gear shaft and middle shaft >
1. Remove the 2
nd
gear shaft(1) with bearings.
2. Remove the 3
rd
shaft assembly(2) and shift
fork(3) with shift rod.
3. Remove the middle shaft(4) and 19T gear with
bearing.
▷ Reassembling
9 When assembling the 19T gear(5), face the
chamber side to the front.
9 Install the shift fork(3), so that the snap ring(7) of
the shift rod(6) faces rearward.
*. PART NAME
1) 2
nd
gear shaft 2) 3
rd
shifter assembly
3) Shaft fork 4) Middle shift
5) 19T Gear 6) Shift fork rod
7) External snap ring
A) Rear
< Front wheel drive shaft >
1. Remove the external snap ring and remove the
20T shifter gear(1).
2. Draw out the front wheel drive shaft(2) to the
front.
*. PART NAME
1) 20T Shifter gear 2) Front wheel drive shaft
< Mid-PTO shaft >
1. Remove the oil seal(1) and internal snap ring(2).
2. Remove the mid-PTO shaft(3) with bearing(4).
▷ Reassembling
9 Apply grease to lip and out of oil seal.
*. PART NAME
1) Oil seal 2) Internal snap ring
3) Mid-PTO Shaft 4) Bearing
(1)
(2)
(3)
(4)
(5)
(6)
(6) (7)
(3)
(1)
(2)
(1)
(3)
(1)
(2)
(4)
(3) (4)
