Qualified cables for the FC8-64 port blade
A
Qualified cables for the FC8-64 port blade
Table 23 lists the third party cables that have been qualified for use with the mSFP transceivers in
the FC8-64 high density port blade.
TABLE 23 Qualified cables for mSFP connections for the FC8-64 high density port blade
Description Length Corning part number Molex part number Amphenol part number
Patch cables - mSFP to LC S50502S5120XXXM
(XXX = length)
943-99865-1XXXX
(XXXX = length)
mSFP LC - standard LC, duplex,
multi-mode, OM3, 50/125
1 m S50502S5120001M 106273-0525 943-99865-10001
mSFP LC - standard LC, duplex,
multi-mode, OM3, 50/125
2 m S50502S5120002M 106273-0526 943-99865-10002
mSFP LC - standard LC, duplex,
multi-mode, OM3, 50/125
3 m S50502S5120003M 106273-0527 943-99865-10003
mSFP LC - standard LC, duplex,
multi-mode, OM3, 50/125
5 m S50502S5120005M 106273-0528 943-99865-10005
mSFP LC - standard LC, duplex,
multi-mode, OM3, 50/125
10 m S50502S5120010M 106273-0529 943-99865-10010
Patch cables - mSFP to mSFP S5S502S5120XXXM
(XXX = length)
943-99866-1XXXX
(XXXX = length)
mSFP LC - mSFP LC, duplex,
multi-mode, OM3, 50/125
1 m S5S502S5120001M 106273-0560 943-99866-10001
mSFP LC - mSFP LC, duplex,
multi-mode, OM3, 50/125
2 m S5S502S5120002M 106273-0561 943-99866-10002
mSFP LC - mSFP LC, duplex,
multi-mode, OM3, 50/125
3 m S5S502S5120003M 106273-0562 943-99866-10003
mSFP LC - mSFP LC, duplex,
multi-mode, OM3, 50/125
5 m S5S502S5120005M 106273-0563 943-99866-10005
mSFP LC - mSFP LC, duplex,
multi-mode, OM3, 50/125
10 m S5S502S5120010M 106273-0564 943-99866-10010
Trunk cables - mSFP to MTP tbd
mSFP LC - MTP-female, 12 fiber,
12" breakout, OM3, 50/125
H93S5TE9-BMU-XXXM
(XXX = length)
943-99867-1XXXX
(XXXX = length)
mSFP LC - MTP-female, 12 fiber,
6" breakout, OM3, 50/125
2m 106272-0327
mSFP LC - MTP-female, 24 fiber,
12" breakout, OM3, 50/125
2m 106272-0328
Bag of clips (quantity 64) TRIGGER-BP-NP n/a n/a
