Brocade Communications Systems DCX 8510-4 User Manual

Brocade DCX 8510-4 Backbone Hardware Reference Manual 43
53-1002177-06
Determining the status of a port or application blade
4
Blade illustrations
FIGURE 6 FC8-64 port blade
NOTE
The FC8-64 port blade requires narrower OM-3 LC cables offered by major manufacturers like
Corning, Molex, and Amphenol.
FIGURE 7 FC8-32E port blade
1 Status LED 3 Fibre Channel port
2 Power LED 4 Port Status LED
1 Status LED 3 Fibre Channel port
2 Power LED 4 Port Status LED
1
2
3
4
1
3
4
2
