Brocade DCX 8510-4 Backbone Hardware Reference Manual 17
53-1002177-06
Items included with the Brocade DCX 8510-4
2
Items included with the Brocade DCX 8510-4
The Brocade DCX 8510-4 ships with the following:
• Brocade DCX 8510-4 chassis, populated with:
- Control processor blades (CP8)
- Core switch blades (CR16-4)
- Port blades, application blades, and encryption blades (included based on customer
specification)
- Blade slot filler panels (for slots not filled by blades)
- Port side exhaust kit (included based on customer specification)
- WWN cards
- WWN bezel (logo plate)
- Power supplies
- Power supply filler panel (included if there is only one power supply)
- Blower assemblies
- Cable management finger assemblies
- Chassis door
• Accessory kit containing the following items:
- Brocade DCX 8510-4 Backbone QuickStart Guide
- Brocade Documentation CD (contains documents related to the Brocade DCX 8510-4)
- ESD grounding strap
- USB device
- RS-232 serial cable. The RS-232 cable has an adapter at one end that can be removed to
provide an RJ45-style connector.
• Rack mount kit (as ordered) with instructions
Order the Brocade-branded optical transceivers (SFP+, mSFP, and QSFP). The Brocade DCX 8510-4
supports SWL, LWL, and ELWL transceivers. The mSFPs and QSFPs are SWL transceivers only.
NOTE
For information about the SFP+, mSFP, and QSFP transceivers that are qualified for the Brocade
DCX 8510-4, go to
http://www.brocade.com/downloads/documents/matrices/Brocade_Compatibility_Matrix.pdf.
Providing power to the Brocade DCX 8510-4
For this procedure, please see “Power specifications” for power supply requirements for your
chassis.
