32 Brocade DCX 8510-4 Backbone Hardware Reference Manual
53-1002177-06
Determining installed software licenses
3
Determining installed software licenses
Depending on the vendor agreement, certain licenses are factory installed on the Brocade DCX
8510-4. To determine which licenses are enabled, use the licenseShow command.
swDir:admin> licenseshow
AAbbccDDeeFFeeGG:
Web license
Zoning license
Extended Fabric license
Fabric Watch license
Performance Monitor license
Trunking license
Security license
In this example, the license key is AAbbccDDeeFFeeGG. Keep a copy of the license key for
reference.
The 64-bit chassis ID is required to obtain and activate licenses for the Brocade DCX 8510-4. The
chassis ID is available through the licenseIdShow command. The licenseShow and licenseIdShow
commands must be entered on the active CP blade. Refer to the Fabric OS Administrator’s Guide
for more information.
Installing transceivers and attaching cables
The following two sets of steps cover the installation of transceivers and cables for most SFPs and
for QSFPs.
Installing SFP+ and mSFP transceivers and cables
Complete the following steps to install SFP-type optical transceivers.
NOTE
mSFP transceivers are compatible only with the FC8-64 port blade. While they will fit in other
blades, this configuration is unsupported and will generate an error.
The ports are color-coded to indicate which can be used in the same port group for trunking
(trunking port groups can be up to eight ports). The ports and cables used in trunking groups must
meet specific requirements. Refer to the Fabric OS Administrator’s Guide for more information.
1. Add the optical transceivers and cables to the Fibre Channel ports.
The ports are color-coded to indicate which can be used in the same port group for trunking
(trunking port groups can be up to 8 ports). The ports and cables used in trunking groups must
meet specific requirements. Refer to the Fabric OS Administrator’s Guide.
2. Position one of the optical transceivers so that the key is oriented correctly to the port. Insert
the transceiver into the port until it is firmly seated and the latching mechanism clicks.
Transceivers are keyed so that they can only be inserted with the correct orientation. If a
transceiver does not slide in easily, ensure that it is correctly oriented.
3. Position a cable so that the key (the ridge on one side of the cable connector) is aligned with
the slot in the transceiver. Insert the cable into the transceiver until the latching mechanism
clicks.
