138 Brocade DCX 8510-4 Backbone Hardware Reference Manual
53-1002177-06
Port Numbering Template
D
FIGURE 44 FX8-24 extension blade
1 10 GbE ports 0-1 5 FC ports 0-5
21 GbE ports 0-3 6Blade Power LED
3 1 GbE ports 4-9 7 Blade Status LED
4FC ports 6-11
2
1
5
4
3
7
6
