Brocade DCX 8510-4 Backbone Hardware Reference Manual 77
53-1002177-06
Power supply removal and replacement
5
1. Open the ejectors by rotating them toward the center of the blade face. Orient the CR blade so
that the handles are toward you.
2. Align the flat side of the blade inside the left and right rail guides in the slot with the
components facing upwards, and slide the blade into the slot until it is firmly seated.
3. Close the ejectors by rotating them away from the center of the blade. The levering action of
the ejectors seats the blade in the slot.
4. Power on the blade by screwing in the thumbscrews.
5. Verify that the power LED is green (might require a few seconds). If not, ensure that the core
switch blade has power and is firmly seated and that the ejectors are in the locked position.
6. The status LED on the new blade is initially amber and will be until POST for the blade
completes. this may take as long as several minutes. It then turns green.
7. Connect the cables to the new core switch blade. For the 8510 models, if the QSFP cables are
not used, make sure the rubber gaskets are in the QSFP transceivers.
8. Replace the chassis door.
9. Pack the faulty core switch blade in the packaging provided with the new core switch blade,
and contact the Brocade DCX 8510-4 supplier to determine the return procedure.
Power supply removal and replacement
Use this procedure to remove and replace a power supply.
The Brocade DCX 8510-4 can continue operating during the replacement if the second 220 VAC
power supply is operating. If the Brocade DCX 8510-4 is supplied with 110 VAC (nominal), there is a
risk of some blades being powered off for lack of power during the replacement.
This is why Brocade always recommends using 220 VAC (nominal).
Brocade DCX 8510-4 power supplies are 100-240 VAC, auto-sensing.
Time and items required
The replacement procedure for each power supply takes less than five minutes. A power supply
unit or filler panel is required for the power supply replacement.
Identifying power supplies
Figure 24 shows the location and identification of the power supplies.
