46 Brocade DCX 8510-4 Backbone Hardware Reference Manual
53-1002177-06
Determining the status of a port or application blade
4
FIGURE 12 FX8-24 extension blade
See “FX8-24 blade” for information about trunking groups on this blade.
1 Status LED 5 10GbE (XGE) port 0
2 Power LED 6 Port status LED for 10GbE port 0
3 GbE (GE) port 6 7 Port map
4 Port status LED for GbE port 6
4
3
5
6
7
2
1
