Determining the status of a port or application blade
4
FIGURE 8 FC8-48E port blade
FIGURE 9 FC16-32 port blade
1 Status LED 3 Fibre Channel port
2 Power LED 4 Port Status LED
1 Status LED 3 Fibre Channel port
2 Power LED 4 Port Status LED
1
3
4
2
1
3
4
2
