184 Brocade MLX Series and NetIron XMR Hardware Installation Guide
53-1003821-01
Installing a NetIron XMR 32000 router
3
FIGURE 126 Routing lower-left quadrant cables
1 Lower left quadrant 3 Cables from slot #18
2 Cables from slot #17 4 Side combs (18)
1
2
3
4
