TABLE 1 Management modules used with Brocade MLXe Series routers (continued)

Part number Description Supported

devices

Introduced Supported Notes

NI-MLX-MR (MR) management module, 1 GB SDRAM,

dual auxiliary ash slots, EIA or TIA-232 and

10/100/1000 Ethernet ports.

MLXe-4,

MLXe-8 and

MLXe-16

MLX-4, MLX-8

and MLX-16

NetIron R05.2.00. NetIron

R05.7.xx.

EOL initiated.

NI-MLX-32-

(MR)-32 management module, 1 GB

SDRAM, dual auxiliary ash slots, EIA or

TIA-232 and 10/100/1000 Ethernet ports.

MLXe-32

MLX-32

NetIron R05.2.00. NetIron

R05.7.xx.

EOL initiated.

NI-XMR-MR (MR) management module, 2 GB SDRAM,

dual auxiliary ash slots, EIA or TIA-232 and

10/100/1000 Ethernet ports.

MLXe-4,

MLXe-8 and

MLXe-16

NetIron R05.2.00. NetIron

R05.7.xx.

EOL initiated.

NI-XMR-32-

(MR)-32 management module, 2 GB

SDRAM, dual auxiliary ash slots, EIA or

TIA-232 and 10/100/1000 Ethernet ports.

MLXe-4,

MLXe-8 and

MLXe-16

NetIron R05.2.00. NetIron

R05.7.xx.

EOL initiated.

The following table describes all supported interface modules for the Brocade MLXe Series routers.

TABLE 2 Interface modules used with Brocade MLXe Series routers

Part number Description Supported

device(s)

Introduced Supported Notes

BR-

MLX-100GX1-

One (1)-port 100 GbE (X) module with IPv4/

IPv6/MPLS hardware support. Supports 1M

IPv4 routes in FIB in XMR mode and 512K

IPv4 routes in MLX mode.

MLXe-4,

MLXe-8,

MLXe-16 and

MLXe-32

MLX-4, MLX-8

MLX-16 and

MLX-32

NetIron R05.6.00e. Yes Requires CFP optics

and high speed

switch fabric

modules.

License

upgradeable to 2

ports on MLXe.

BR-

MLX-100GX2-

CFP2-M

Two (2)-port 100 GbE (M) module with IPv4/

IPv6/MPLS hardware support. Supports

512K IPv4 routes in FIB.

MLXe-4,

MLXe-8,

MLXe-16 and

MLXe-32

NetIron R05.7.00. Yes Requires CFP2

optics and high

speed switch fabric

modules.

BR-

MLX-100GX2-

CFP2-X2

Two (2)-port 100 GbE (X2) module with IPv4/

IPv6/MPLS hardware support. Supports

simultaneous 2M IPv4 and 0.8M IPv6, or

simultaneous 1.5M IPv4 and 1M IPv6 routes

in FIB.

MLXe-4,

MLXe-8,

MLXe-16 and

MLXe-32

NetIron R05.7.00. Yes Requires CFP2

optics and high

speed switch fabric

modules.

BR-

MLX-100GX2-

2-port 100-GbE (X) Module with IPv4/IPv6/

MPLS hardware support. Supports 1M IPv4

routes in FIB in XMR mode and 512K IPv4

routes in MLX mode.

MLXe-4,

MLXe-8,

MLXe-16 and

MLXe-32

NetIron R05.6.00e. Yes Requires CFP optics

and high speed

switch fabric

modules.

BR-

MLX-10GX4-

IPSEC-M

Eight port (4-port 10-GbE and 4-port 1-GbE)

(M) IP Security (IPSEC) module with IPv4/

IPv6/VRF hardware support. Supports 512K

IPv4 routes in FIB.

MLXe-4,

MLXe-8,

MLXe-16 and

MLXe-32

NetIron R05.8.00. Yes Requires SFP+ and

SFP optics and high

speed switch fabric

modules.

BR-

MLX-10Gx20-

Twenty (20)-port 10-GbE/1-GbE (M) combo

module with IPv4/IPv6/MPLS hardware

support. Supports 512K IPv4 routes in FIB.

MLXe-4,

MLXe-8,

MLXe-16 and

MLXe-32

NetIron R05.7.00. Yes Requires SFP+ and

SFP optics and high

speed switch fabric

modules.

BR-

MLX-10Gx20-

Twenty (20)-port 10-GbE/1-GbE (X2) combo

module with IPv4/IPv6/MPLS hardware

support. Supports simultaneous 2M IPv4 and

MLXe-4,

MLXe-8,

NetIron R05.7.00. Yes Requires SFP+ and

SFP optics and high

Supported hardware and software

Brocade NetIron MLXe Series Hardware Installation Guide

14 53-1004203-04
