Cable routing for the upper-right quadrant
Route cables from slots in numerical order starting with the cables for slot #15.
1. Route cables from slots #15 and #16 directly to the right through the side comb, as shown in the following gure.
FIGURE 79 Routing Upper-right quadrant cables to the right
1. Upper right quadrant
2. Cables from slot #15
3. Side combs (18)
4. Cables from slot #16
Installing a Brocade MLXe Series-32 router
Brocade NetIron MLXe Series Hardware Installation Guide
160 53-1004203-04
