NOTE
3000W power supplies do not support low line AC Input Voltage.
The following table lists power consumption, in watts, for Brocade MLXe Series router components.
TABLE 48 Maximum power consumption for Brocade MLXe Series router components
Component Maximum power consumption, in watts
Management modules
MR Management modules (MLXe-4, 8, and 16 routers) 30W
MR Management module (MLXe-32 routers) 35W
MR2 management module (BR-MLX-32-MR2-M for MLXe routers) 45W
MR2 management module (BR-MLX-MR2-M for MLXe routers) 40W
Switch fabric modules
NI-X-SF3 switch fabric module 53W
NI-X-SF1 switch fabric module 19W
NI-X-32-SF switch fabric module 60W
High speed switch fabric modules
NI-X-4-HSF switch fabric module (MLXe-4 routers) 19W
NI-X-16-8-HSF switch fabric module (MLXe-8 and MLXe-16 routers) 53W
NI-X-32-HSF switch fabric module (MLXe-32 routers) 60W
Interface modules
1-port 100 Gbps Ethernet interface module 485W
2-port 100 Gbps Ethernet interface module 640W
2-port 10 Gbps Ethernet interface module (XMR routers)
2-port 10 Gbps Ethernet interface module with ber-optic transceivers
(MLXe routers)
150W
4-port 10 Gbps Ethernet interface module with ber-optic transceivers
(MLXe routers)
225W
4-port 40-GbE Ethernet module (M) 320W
8-port 10 Gbps SFPP module (M) 246W
8-port 10 Gbps SFPP interface module (D) 246W
8-port 10 Gbps interface module (X) 270W
20-port Gbps Ethernet ber Interface with ber-optic transceivers (MLX
routers)
175W
20-port Gbps Ethernet copper Interface module 146W
24-port 1 Gbps Ethernet copper RJ45 interface module 160W
24-port 1 Gbps Ethernet ber interface module 160W
24-port 10 Gbps Ethernet interface module 320W
48-port Gbps Ethernet with MRJ-21 interface 260W
Hardware specications for Brocade MLXe Series routers
Brocade NetIron MLXe Series Hardware Installation Guide
272 53-1004203-04
