Operation Manual
FT1020G3 Rev 2.4
35
User level 0
With the door closed, no access, controls indicators are viewed through outer door.
User level 1
28
After the door has been opened using 003 key ("Door open" symbol in the symbol
field), the designated user / fire brigade personnel will have access to the
following push buttons:
Push button Operation/function
Silence the buzzer in FT1020G3
P2 Silence all alarm devices (OWS or sounders).
P3 Reset fire alarms (S) (see below)
P4 Disable active alarm (S)
P9 Scroll / browse through the active queued alarms
OWS OWS controls, if fitted
AS1668 Fan / Damper Control Manual override of AS1668 fans or Damper Control, if fitted
Zone Disablement Quick access to zone disable / re-enable, if fitted
User level 2A
After the door has been opened with 003 key ("Door open" symbol in the symbol
area), you have access to level 1 and after log on as “Information only” (level 2A), the
following menus are accessible:
U1 Disablement
U2 Disablement by time channel
U5 Sensors activating SERVICE signal
U6 Technical warning
U7 Event log
H6 FAULT Acknowledge, Note: Information only
H9 Interlocking outputs and inputs
C1 Activated interlocking outputs / inputs
H10 Change password (In this case for “Information only”)
28
Access to new 19” rack display modules as shown in Figure 11 page 29 will also be possible.
