Brooks Automation Appendices
Part Number: 603988 Rev. A
Appendix A:Product Spe-
cifications
General Specification Range
Pneumatic Lines
One air line, 75 PSI maximum, provided at outer link and routed
internally to fittings on the Facilities Panel if Pneumatic Option
selected.
Operator Interface
Web based operator interface supports local or remote control via
browser connected to embedded web server.
Programming Interface
Three methods available: DIO MotionBlocks (PLC), embedded
Guidance Programming Language (standalone), PC controlled
over Ethernet using TCP/IP.
Required Power
The robot’s power supplies have an input range of 100 to 240
VAC, +/- 10%, 50/60 Hz. 200 Watts typical 400 watts maximum
Weight, XZTG version 22 kg for 635 mm travel version, 32 kg for 1270 mm version
Copyright © 2023 Brooks Automation, Inc.
119
