Brooks PreciseFlex 100 - Appendix C: Spare Parts List

Brooks Automation Appendices
Part Number: 603988 Rev. A Appendix C: Spare Parts List
Appendix C: Spare Parts List
Description Part Number
Absolute Encoder Battery Assembly, D cell PF00-EA-00002
X-axis Motor Assembly PP00-MA-00053
Y-axis Motor Assembly PP00-MA-00201
Z Motor Assembly PP00-MA-00051
Theta Motor Assembly PF03-MA-00001-E3
Gripper Motor Assembly PF04-MA-00004-E2
X-axis 12 mm belt 635 mm X travel, for XZ robot PP00-MC-X0006 1588 mm length
X-axis12 mm belt 1270 mm X travel, for XZ robot PP00-MC-X0006 2855 mm length
X-axis 15 mm belt 500 mm X travel, for XYZ robot PP00-MC-X0034-5
X-axis 15 mm belt 1090 mm X travel, for XYZ robot PP00-MC-X0034-9
Y-axis belt 350 mm travel PP00-MC-X0006
Z-axis motor belt PP00-MC-X0028
Z-axis output belt, 229 mm travel PP00-MC-X0029
Z-axis output belt, 260 mm travel PP00-MC-X0029
Gripper Spring and Cable Assembly PP00-MA-00055
G1400D Controller G1XF-EA-A1400
G1100T Slave Controller SE (“GSB3”) G1X0-EA-T1101
G1100T Slave Controller Diff (“GSB3”) G1X0-EA-T1101-4D
GIO Digital IO Board with pigtails GIO1-EA-01104
24VDC Supply PS10-EP-00125
48VDC Motor Supply PS10-EP-48365
Estop Box PP10-EA-00022
Pendant PP10-EA-00013
Harness, Gripper PP0H-MA-00001
Encoder Wiring PCA PP1C-EA-00001
