Brooks Automation 6. Service Procedures
Part Number: 603988 Rev. A
Replacing the Y-axis Belt
Assembly (For XY robots only)
Replacing the Y-axis Belt Assembly (For XY robots only)
Electrical Shock
Working with energized equipment may cause electrical shock and may result in serious
injury or death.
l
Remove the AC power before replacing the Y-axis Motor or Belt.
To replace the Y-axis belt, loosen the belt clamp screws on the Y-axis carriage (see Figure 6-2).
Figure 6-2: Y-axis Carriage and Belt
Copyright © 2023 Brooks Automation, Inc.
99
