Replacing the Servo Gripper
Controller
Replacing the Servo Gripper Controller
Electrical Shock
Working with energized equipment may cause electrical shock and may result in serious
injury or death.
l
Remove the AC power before replacing the Gripper Control.
Tools Required
l
2.0 mm hex driver or hex L wrench
l
2.5 mm hex driver or hex L wrench
Spare Parts Required:
l
Guidance Gripper Controller (P/N G1X0-EA-T1101)
To replace the Gripper Controller, perform the following procedure:
Step Action
1.
Turn off the robot power and remove the AC power cord.
2.
Remove the Theta Cover.
3.
Remove the Gripper Controller by removing the (4) M3 X 8 mm SHCS and unplugging the
cables.
4.
Replace the Gripper Controller and re-attach the harness.
5.
Replace the Theta Link Cover.
6.
It is not necessary to recalibrate the robot after replacing the Gripper Controller.
