6. Service Procedures PreciseFlex 100 Robot
Replacing the Main Harness Part Number: 603988 Rev. A
Step Action
8.
Reconnect the cables as shown.
9.
Replace the rear cover.
10.
Recalibrate the robot.
Replacing the Main Harness
Replacement of the Main Robot Harness is typically only performed at the factory. The Main Robot
Harness is intended to last for the life of the robot.
106
