Appendices PreciseFlex 100 Robot
Appendix B: Environmental Specifications Part Number: 603988 Rev. A
Appendix B: Environmental Specifications
The PreciseFlex
TM
Robots must be installed in a clean, non-condensing environment with the
following specifications:
General Specification Range & Features
Ambient temperature 4º C to 40º C
Indoor use only
Storage and shipment temperature -25º C to +55º C
Humidity range 10 to 55%, non-condensing, non-corrosive
Altitude Up to 3000 m
Voltage 100-240 VAC +/- 10%, 50/60 Hz
Mains cord rating, min 18AWG, 3 conductor, 5 Amps min
Pollution Degree 2
Approved Cleaning Agents IPA, 70% Ethanol/30% water, H2O2 Vapor up to 1000 ppm
IP rating 11
IK impact rating IK08: 5 Joule
120
