3. Installation Information PreciseFlex 100 Robot
Environmental Specifications Part Number: 603988 Rev. A
3. Installation Information
Environmental Specifications
The PreciseFlex™ robots must be installed in a clean, non-condensing environment. Light fluid
splashing around the base of the robot is acceptable, but this robot is not intended for use in a
washdown or spray environment. See Environmental Specifications in Appendix B for specific
environmental limits.
Facilities Connections
See Appendix F: Facilities Panel for details of the Facilities Panel.
Specifications and System Dimensions
General
Specifications
Range & Features
Range of Motion & Resolution
X-axis l
500 mm standard, 1090 mm option available in XYZ version
l
685 mm standard, 1270 mm option available in XZ version
Y-axis 350 mm standard
Z-axis l
260 mm standard in XYZ version
l
229 mm standard in XZ version
Theta Axis +/- 270 degrees
Figure 3-1: Specifications, Ranges & Features
