4. Hardware Reference PreciseFlex 100 Robot
System Schematics, Diagram, and Power Supplies Part Number: 603988 Rev. A
ground bypassing the transistor that performs this function under computer power so that the brake
can be released manually without motor power being enabled.
Figure 4-1: PP100 Robot Electrical System Diagram
50
Copyright © 2023 Brooks Automation, Inc.
