10 CLEANING
BM-2000
67
8. Insert the nozzle cleaning pin 1.5 (7) into the screw hole
in the nozzle (2) to remove any blockages from the glue
path in the nozzle (2).
9. Install the screws (5) to the nozzle (2).
* Install the two screws.
10. Discharge the glue and check that glue come out from all
of the discharge holes in the nozzle (2). (Refer to “4.2” for
details on the discharging method.)
* If glue is not coming out from all of the discharge holes
in the nozzle (2), clean the discharge holes of the
nozzle (2) once more.
(7)
(2)
(5)
(5)
(2)
(2)
