Brother BM-2000 - Adjusting the Nozzle Position (Feed Direction)

11 PART REPLACEMENT METHOD
BM-2000
81
11.1.2 Adjusting the nozzle position (feed direction)
1. Display the memory switch setting screen. Refer to "3.5" for details on the display method.
2. Change the setting value for memory switch No. 411 so that the center of the nozzle screw is directly above the center
of the nozzle lower roller shaft. The larger the value, the further forward the nozzle will move.
No.
Name
Details
Setting
range
Step
Initial
value
411
Nozzle lever application
position correction
Correction amount for application
position (position a)
-120～120
4
0
Nozzle lower roller shaft
Nozzle screw
