Brother BM-2000 - List of Memory Switch Settings (for Mechanism)

3 USING THE OPERATION PANEL AND SWITCHES
BM-2000
25
No.
Name
Setting
Setting range
Unit
Initial
value
427
X-over detection - cloth plate
raising position correction
Correction distance for cloth plate
raising position when an X-over seam
is detected
-11.0 - 20.0 [mm]
0.1
0.0
430
Lower material presser
Lower material presser
OFF: Disabled ON: Enabled
OFF, ON
-
ON
500
Nozzle glue width
Gluing width of installed nozzle
6 - 10 [mm]
2
8
522
Operation when upper roller
stops
Upper roller pressure after paused
OFF: Pressure off
ON: Pressure on
OFF, ON
-
OFF
531
Feeding amount after and
detection
Feed amount after detecting lower
material end (mm)
0.0 - 25.0 [mm]
0.5
0.0
532
Feed distance after gluing
stops
Feed distance until feed stops after
gluing stops
OFF: Does not stop
OFF,
1 - 100[mm]
1
OFF
601
Warning level for low amount
of glue
Amount of remaining glue for
displaying warning dialog
1 - 5[%]
1
3
3.5.5 List of memory switch settings (for mechanism)
No.
Name
Setting
Setting range
Unit
Initial
value
11
Treadle mode for bonding
preparation
Selection of treadle operation method
during preparation for gluing
1 - 2
1
2
86
Treadle – Number of speed
steps
Number of steps in the variable speed
range for the treadle
OFF,
2 - 30
1
20
250
Max. feed speed
Max. feed speed
0.5 - 5.0
[m/min]
0.1
5.0
252
Feed speed during reverse
mode
Feed speed during reverse mode
0.5 - 5.0
[m/min]
0.1
1.0
273
Feed motor excitation while
paused
Feed motor excitation status when
stopped
OFF, ON
-
ON
274
Pump motor excitation while
paused
Pump motor excitation status when
stopped
OFF, ON
-
OFF
550
Target temperature for
melter
Target temperature for melter
80 - 145[°C]
5
90
551
Target temperature for pump
Target temperature for pump
80 - 145[°C]
5
120
552
Target temperature for
nozzle
Target temperature for nozzle
80 - 145[°C]
1
125
553
Max pump speed
Pump speed upper limit
5 - 50[rpm]
1
42
554
Time out for temperature
control
Temperature control timeout time
10 - 60[min]
5
30
555
Wait duration after reaching
target temperature
Wait time after target temperature is
reached
3 - 15[min]
1
5
556
Wait time after cartridge
replacement
Wait time after cartridge replacement
5 - 30[min]
1
15
560
Temperature of melter during
sleep mode
Melter temperature during sleep mode
OFF,
60 - 145[°C]
5
70
561
Temperature of pump during
sleep mode
Pump temperature during sleep mode
OFF,
60 - 145[°C]
5
60
562
Temperature of nozzle
during sleep mode
Nozzle temperature during sleep
mode
OFF,
60 - 145[°C]
1
80
565
Temperature of melter during
boot
Melter temperature during startup
80 - 145[°C]
5
125
566
Minimum duration for melter
heating during boot
Melter heating time lower limit value
during startup
10 - 60[min]
1
15
571
Minimum melter pressure
Melter pressurization lower limit
100 - 200
[KPa]
10
100
572
Maximum melter pressure
Melter pressurization upper limit
200 - 300
[KPa]
10
300
