5.3 Setting edge control roller pressure
Changing edge control roller pressure
The pressure of the edge control rollers which controls the edge of the cloth can be changed.
* When gluing a cloth which the edge control rollers slide over easily, increase the pressure of the edge control rollers.
Puckering can easily occur when using stretch cloth, so return the value to the setting at the time of shipment from the
factory.
1. Make the pressure of the upper edge control roller stronger than the value at the time of shipment from the factory.
(1) Use a spanner to loosen the nut A, and turn it until is at the same position as the right-hand edge of the thread.
(2) Turn the nut B all the way to the right, and then use a spanner to tighten it.
