12 STANDARD ADJUSTMENTS
BM-2000
89
2. Adjust the position of the anti-entanglement plate (6) so that the clearance between the upper roller (4) and the anti-
entanglement plate (6) is as small as possible (around 0.1 mm) without the two parts touching.
3. Tighten the screws (5) to secure the anti-entanglement plate (6).
(6)
(4)
Clearance
