Brother DCP-8065DN

Confidential
5-15
Scanner unit (Scanner motor , FB FG harness)
20
Drive plate ASSY
Driver PCB
Hole
Scanner unit
Scanner motor
FB FG harness
Scanner unit (CCD module , HP sensor)
19
Main PCB
CCD module
FFC cable
HP sensor
HP sensor
Drive plate ASSY
Drive plate ASSY
HP sensor harness
FFC plate
Hole
Scanner unit
Hook
Pin
Rib

