Confidential
5-19
Driver PCB , Battery
28
Main PCB
Driver PCB
Joint cover
Driver harness
Battery harness
Battery
Hole
Main motor ASSY AL , Thermistor ASSY , LT connector
Frame L
Thermistor ASSY
Thermistor ASSY
Main motor ASSY AL
LT connector
27
Main PCB
