Brother DCP-8065DN

6-43 Confidential
(3) Put the Holder bearing MP into the MP feed frame and turn the Holder bearing MP to the
direction of the arrow 3c to lock.
Fig. 6-80
(4) Close the MP feed frame cover.
Fig. 6-81
Hook
Holder bearing MP
MP feed frame
3c
3a
3b
Front cover
MP feed frame
MP feed frame cover
