- Selectors 6 and 7: Dial tone detection in PABX (Not used.)
These selectors activate or deactivate the dial tone detection function which detects a dial tone
when a line is connected to the PABX.
Setting both of these selectors to "1" activates the dial tone detection function so that the machine
starts dialing upon detection of a dial tone when a line is connected.
Other setting combinations deactivate the dial tone detection function so that the machine starts
dialing after the specified WAIT (3.5, 5.0, or 7.0 sec.) without detection of a dial tone when a line
is connected.
WSW04 (TRANSFER facility setting)
Selector
No.
Function
Setting and Specifications
1
Earth function in transfer facility
(Not used.)
0: Provided 1: Not provided
2
3
Dual tone detection frequency in
ICM recording
(Not used.)
No. 2 3
0 0 : 350 and 440 Hz (A)
0 1 : 440 and 480 Hz (B)
1 0 :
1 1 :
4
Dual tone detection sensitivity in
ICM recording
(Not used.)
0: Normal 1: High
5
Added time to maximum OGM
recording time (WSW24 Selector 1,
2) and erasing time length of ICM
tone recorded preceding the tone
detection starting point in the case
of automatic line disconnection due
to no voice signal received
(WSW34 Selector 1 to 3).
0: Not added
1: +4 seconds added
6
|
8
Break time length for flash function
No. 6 7 8
0 0 0 : 80 ms
0 0 1 : 100 ms
0 1 0 : 110 ms
0 1 1 : 120 ms
1 0 1 : 200 ms
1 0 1 : 250 ms
1 1 0 : 500 ms
1 1 1 : 700 ms
NOTE: Selectors 1 and 5 through 8 are not applicable in those countries where no transfer facility is
supported.
NOTE: Selectors 2 through 4 are applicable to models equipped with built-in TADs.
- Selector 1: Earth function in transfer facility (Not used.)
This selector determines whether or not the earth function is added to the transfer setting menu to
be accessed by the function switch.
480 and 620 Hz (C)

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
