App. 4-19 Confidential
WSW15
(REDIAL facility setting)
Selector
No.
Function Setting and Specifications
1
2
Redial interval
No. 1 2
0 0 : 5 minutes
0 1 : 1 minute
1 0 : 2 minutes
1 1 : 3 minutes
3
|
6
No. of redialings
No. 3 4 5 6
0 0 0 0 : 16 times
0 0 0 1 : 1 times
0 0 1 0 : 2 times
0 0 1 1 : 3 times
| |
1 1 1 1 : 15 times
7 Not used.
8 CRP option
0: Disable 1: Enable
- Selectors 1 through 6: Redial interval and No. of redialings
The machine redials by the number of times set by selectors 3 through 6 at intervals set by
selectors 1 and 2.
- Selector 8: CRP option
If a command error occurs in the machine (calling station), the machine usually waits for three
seconds and then makes a retry three times. This CRP option is a request command that can be
sent from the called station for requesting the calling station to retry the failed command
immediately.
