Brother DCP-8065DN Service Manual

App. 4-25 Confidential
- Selectors 8: Limitation on CNG detection
If this selector is set to "1," the machine detects a CNG signal according to the condition preset by
selectors 2 and 3 on WSW18 after a line is connected. If it is set to "0," the machine detects a
CNG signal as long as the line is connected.
WSW21 (TAD setting 1)
Selector
No.
Function
Setting and Specifications
1
|
5
Max. waiting time for voice
signal (Not used.)
No. 1 2 3 4 5
0 0 0 0 0 : No detection
0 0 0 0 1 : 1 sec.
0 0 0 1 0 : 2 sec.
0 0 0 1 1 : 3 sec.
| |
0 1 0 0 0 : 8 sec.
| |
1 1 1 1 1 : 31 sec.
6
7
Taping the call (Not used.)
No. 6 7
0 0 : Enable (signaling for U.S.A.)
0 1 : Enable (signaling for countries
except U.S.A.)
1 0 : Enable (without signaling)
1 1 : Disable
8
Erasure of message stored in
the memory after the message
transfer
0: Yes 1: No
NOTE: Selectors 1 through 5 are applicable to models equipped with ICM recorders.
NOTE: Selectors 6 and 7 are applicable to models with internal TADs.
NOTE: Selector 8 is applicable to models equipped with TADs.
- Selectors 1 through 5: Max. waiting time for voice signal (Not used.)
In the TAD mode, the machine waits for voice signal for the time length specified by these
selectors before it automatically shifts to the facsimile message receive mode or disconnects the
line.
- Selectors 6 and 7: Taping the call (Not used.)
These selectors select whether or not to tape the call. Setting them to "1, 0" enables taping the call
without signaling to the calling station that the call is being taped.
- Selector 8: Erasure of message stored in the memory after the message transfer
Setting this selector to "0" will erase the message recorded in the memory after the document
retrieval feature transfers the message.

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
