Brother DCP-8065DN Service Manual

App. 4-31 Confidential
WSW27
(Function setting 5)
Selector
No.
Function Setting and Specifications
1 Not used.
2 Ringer OFF setting 0: Yes 1: No
3
Automatic playback of OGM when
switched to the TAD mode
(Not used.)
0: No 1: Yes
4
Detection of distinctive ringing
pattern
0: Yes 1: No
5 Not used.
6 Recording quality 0: Normal 1: High
7
Recording time for high recording
quality
0: Short 1: Long
(9.6 kbps) (8.8 kbps)
8 Not used.
NOTE: Selectors 4 and 5 are applicable to the U.S.A. models only.
- Selector 2: Ringer OFF setting
This selector determines whether or not the ringer can be set to OFF.
- Selector 3: Automatic playback of OGM when switched to the TAD mode (Not used.)
This selector determines whether or not to automatically play back an OGM the moment the
machine switches to the TAD mode.
- Selectors 4: Detection of distinctive ringing pattern
If this selector is set to "1," the machine detects only the number of rings; if it is set to "0," the
machine detects the number of rings and the ringing time length to compare the detected ringing
pattern with the registered distinctive one.
- Selector 6: Recording quality
This selector determines the recording quality for the OGM and ICM. Selecting "1" (High)
increases the quality, sacrificing the recording time.
- Selector 7: Recording time for high recording quality
This setting takes effect when selector 6 is set to "1" (High). Setting this selector to "0" (Short)
further increases the recording quality, sacrificing the recording time.
The recording quality and time to be applied when this selector is set to "1" (Long) are higher and
shorter than the ones to be applied when selector 6 is set to "0" (Normal).
The recording quality and time determined by this selector being set to "1" (Long) are higher and
shorter than the ones determined by selector 6 being set to "0" (Normal).

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
