Brother DCP-8065DN Service Manual

App. 4-35 Confidential
WSW31
(Function setting 9)
Selector
No.
Function
Setting and Specifications
1 Not used.
2
Default reduction rate for
failure of automatic reduction
during recording
0: 100% 1: 70%
3 Not used.
4 (Do not disturb this selector.)
5
Minimum ON and OFF
duration of ringer signals
effective in distinctive ringing
0: 130 ms 1: 90 ms
6
|
7
Not used.
8 "CHANGE DRUM" display 0: Yes 1: No
NOTE: Selector 5 is applicable only to the U.S.A. models.
- Selector 2: Default reduction rate for failure of automatic reduction during recording
This selector sets the default reduction rate to be applied if the automatic reduction function fails
to record one-page data sent from the calling station in a single page of the current recording paper.
If it is set to "0," the machine records one-page data at full size (100%) without reduction; if it is
set to "1," the machine records it at 70% size.
- Selector 5: Minimum ON and OFF duration of ringer signals effective in distinctive ringing
The ringer pattern consists of short and long rings, e.g., short-short-long rings. This selector sets
the minimum ON and OFF duration of ringer signals that are required for the machine to interpret
ringer signals as being ON or OFF. This is to prevent components of a ringer pattern from being
misinterpreted due to chattering in distinctive ringing.
The machine monitors ringer signals at 10-ms intervals. If the signal is ON, the machine counts
+1; if it is OFF, it counts -1. If the counter increments up to +5 or +13 when this selector is set to
"1" (50 ms) or "0" (130 ms), respectively, the machine interprets the current signal as being ON.
If the counter returns to zero, the machine interprets the signal as being OFF.
If the Distinctive Ring is set to OFF, this selector is not effective.
- Selector 8: "CHANGE DRUM" display
This selector determines whether or not the "CHANGE DRUM" display should appear on the
LCD when the service life of the laser-sensitive drum in the laser unit will expire soon.

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
