Brother DCP-8065DN Service Manual

App. 4-41 Confidential
- Selectors 6 through 8: Extension of incoming calling signal (CI) frequency band specified by selectors
1 through 4 on WSW14
At the start of reception, if the machine detects the frequency of a CI signal specified by selectors
1 through 4 on WSW14, it starts the ringer sounding. However, the machine may fail to detect the
CI signal normally due to noise superimposed at the time of reception. To prevent it, use selectors
6 through 8 on WSW36.
If the machine detects higher frequencies than the setting made here, it regards them as noise and
interprets the detecting state as being normal, allowing the ringer to keep sounding according to
the preset number of ringers (until it starts automatic reception of FAX data in the FAX mode or
enters the TAD mode in the TEL mode).
WSW37 (Function setting 15)
Selector
No.
Function
Setting and Specifications
1
Printout of the stored image
data of an unsent document
onto an error report
0: No 1: Yes
2
Erasure of the stored image
data of an unsent document at
the time of the subsequent in-
memory message transmission
0: No 1: Yes
3
|
8
Not used.
- Selector 1: Printout of the stored image data of an unsent document onto an error report
This selector determines whether or not to print out the 1st-page image data of a document onto
the error report if the document image data stored in the temporary memory cannot be transmitted
normally.
- Selector 2: Erasure of the stored image data of an unsent document at the time of the subsequent in-
memory message transmission
If in-memory message transmission fails repeatedly when selector 1 is set to "1," the temporary
memory will be occupied with image data. Setting selector 2 to "1" will automatically erase the
stored 1st-page image data of an unsent document at the time of the subsequent in-memory
message transmission only when recording paper or toner runs out.

Brother DCP-8065DN Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Scan to	e-mail, file, image, OCR
Input color depth	48 bit
Copier resize	25 - 400 %
Maximum copy resolution	1200 x 600 DPI
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	28 cpm
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Internal memory	32 MB
Maximum internal memory	544 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	55 dB
Display	LCD
Market positioning	Business
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Font styles	66 Scaleable fonts, Letter, Gothic 16.66, OCR-A, OCR-B, 11 Barcodes
Dimensions (WxDxH)	531 x 450 x 475 mm
Networking features	10/100 Base-TX
All-in-one functions	Copy, Scan
Color all-in-one functions	scan, n
Compatible operating systems	Mac OS X 10.2.4 or greater Windows XP
Standard interfaces	USB 2.0
Sustainability certificates	ENERGY STAR
Power consumption (standby)	85 W
Power consumption (PowerSave)	15 W
Power consumption (average operating)	660 W
