Brother DCP-8065DN Service Manual

App. 4-50 Confidential
WSW46
(Monitor of power ON/OFF state and parallel port kept at high)
Selector
No.
Function Setting and Specifications
1
2
Monitoring the PC ON/OFF
state
No. 1 2
0 0 : Disable
0 1 : Monitor SELECT IN
1 0 : Monitor STROBE
1 1 : Monitor both SELECT IN and
STROBE
3
Parallel port output pins kept at
high level
0: Enable 1: Disable
4
|
8
Not used.
NOTE: Selector 4 is not applicable to models equipped with flat-bed scanners.
- Selectors 1 and 2: Monitoring the PC ON/OFF state
For the related functions, refer to WSW36, selectors 2 and 3.
- Selector 3: Parallel port output pins kept at high level
Setting this selector to "0" will keep all parallel output pins of the machine at high level. Use this
setting if Resource Manager (bundled with MFC models) installed to WindowsNT running on the
connected PC fails to monitor the power ON/OFF state of the machine.
- Selector 4: Previous filtering parameters for white level compensation
At the start of scanning operation, the machine usually initializes white and black level data stored
in the EEPROM by scanning the while-level reference film attached to the inside of the scanner
top cover. After long use of the machine, however, the film may be contaminated with dust or dirt.
Accordingly, incorrect white level data will be set up so that white vertical streaks will be brought
on the scanning result.
Setting this selector to "0" (Enabled) will apply previously saved white level data instead of new
incorrect compensation.
