Brother MFC-8480DN Service Manual

3-10
Confidential
Error
codes
Problem
Refer
to:
Error
codes
Problem
Refer
to:
7F
Fax paper setting mismatch
(The setting paper becomes
besides the A4/Letter/Legal/
Folio) (Not applicable)
3-23 AD
DMA transfer error
3-31
80
Fax paper size is incorrect (The
paper is smaller 10mm than the
letter size (11inch) in Fax List/
Report)
3-23 AE
Document scanner home
position sensor is not turned on.
3-31
83
Failure of discharge detection
(Printing becomes unable until the
drum is replaced with a new one.)
(Discharge detection becomes
unable until the drum counter
reaches the double of the drum
life.)
3-23 AF
Document scanner home
position sensor is not turned off.
3-32
84
Paper jam
3-24 B0
Document scanner unit FFC
detection error
3-32
85
Tray 1 is not installed into the
machine
3-24 B1
Dark level offset data level error
for scanning
3-33
86
Tray 2 is not installed into the
machine
3-24 B2
Gain control data level error for
scanning
3-33
88
Paper jam inside the machine
3-25 B7
A/D converter standard voltage
failure; at High side
3-33
89
Incorrect paper size in duplex
printing
3-25 B8
A/D converter standard voltage
failure; at Low side
3-33
8A
Paper jam in Tray 1
3-26 B9
Scanning light adjustment error
is detected
3-34
8B Paper jam in Tray 2 3-26 BB White level data error 3-34
8C Paper jam in MP Tray 3-26 BD Black level data error 3-34
8D
Paper jam near eject tray
3-27 BF
ADF duplex scanning cannot be
implemented due to too long
document
3-34
99
Specified paper size is not supported
for duplex printing (Duplex)
3-27 C0
New toner detection lever failure
3-35
9F Paper empty 3-28 C7 Insufficient DIMM Memory 3-35
A1 Front cover opened 3-28 C8 Secure print data full 3-35
A2
During scanning, 90 cm or longer
of a document is detected
3-29 C9
DIMM error
3-36
A3
Document rear sensor is not
turned on when feeding the
document
3-29 CA
Excess current to USB device
that is front side of the machine 3-36
A4
ADF cover opened
3-29 CD
Drum unit is not installed into the
machine
3-36
A5
Fax scanning error (Warning)
(First time)
3-30 D1
Modem initialization failed
3-37
A6
Fax scanning error (Error)
(Second time) 3-30 DD
Fuser error other than 58, 59,
68, 69, 6A, 6B, 6C, 6D, 6E, 6F,
76, 78, DE and E2 are occurred
3-37
A7
Scanning color parameter file
failure 3-30 DE
Central temperature of heat
roller detected the temperature
that was lower than 60°C)
3-37
A8
Scanning color parameter
matching error
3-30 E0
Program error
3-37

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
