Brother MFC-8480DN Service Manual

5-2
Confidential
2. TRANSFERRING RECEIVED FAX DATA
When the machine at the user site requires to be repaired, unplugging the power cord from
the wall socket for sending the machine for repair will lose received FAX data if unprinted and
left in the machine.
To prevent such data loss, the service personnel should instruct end users (e.g., by
telephone) to transfer data to another facsimile machine using the procedure below.
■ Operating Procedure
(1) Connect the machine to be repaired (that has received data in the memory) to the
telephone line.
(2) Switch the machine on.
(3) Press the [Menu], [Start], [Menu] and [ ] buttons in this order.
The "MAINTENANCE 06" appears on the LCD.
(4) Call up the "MAINTENANCE 53" using the [ ] and [ ] buttons and press the [OK]
button.
The "FAX TRANSFER" appears on the LCD.
(5) To check the number of received files
, press the [1] key.
The "1.NO. OF JOBS" appears on the LCD.
Press the [OK] button, and the number of received files appears, just as "NO. OF. JOBS:
10."
Press the [Stop/Exit] button, and the “FAX TRANSFER” appears on the LCD.
(6) To transfer the activity report only
, press the [2] key.
The "2.ACTIVITY" appears.
To transfer received files together with the activity report
, press the [3] key.
The "3.DOCUMENTS" appears. Note that if there is no received file, the "NO
DOCUMENTS" appears.
To transfer the communication list for the latest communication
, press the [4] key.
The "4.COM.LIST (NEW)" appears.
To transfer the communication list for last three errors
, press the [5] key.
The "5.COM.LIST (ERR3)" appears.
Note:
• DCP models do not have this function.
• The number of files that can be transferred at a time is 99. To transfer 100 files or more,
carry out the following procedure more than one time.
TIP:
• If there are both color and monochrome data in a file to be transferred, the monochrome
data will be transferred first. If the receiver machine does not support the color function,
the sender machine cannot transfer color data, resulting in an error.

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
