1. ENTRY INTO THE MAINTENANCE MODE
Press the [Menu] and [Start] buttons. Next press the [ ] button four times to make the
machine enter the maintenance mode.
The machine beeps for approx. one second and displays " " on the
LCD, indicating that it is placed in the initial stage of the maintenance mode, a mode in which
the machine is ready to accept entry from the buttons.
To select one of the maintenance-mode functions listed in "2. LIST OF MAINTENANCE-
MODE FUNCTIONS", press the [ ] button or [ ] button to display any function code on the
LCD. Then press the [OK] button.
(The details of each maintenance-mode function are described in "4. DETAILED
DESCRIPTION OF MAINTENANCE-MODE FUNCTIONS".)
TIP:
• FAX models equipped with numerical keypads can enter the maintenance mode in
the same way as conventional models; that is, by pressing the [Menu] button, [*],
[2], [8], [6] and [4] keys in this sequence.
Note:
• To exit from the maintenance mode and switch to standby, press the [9] key twice in
the initial stage of the maintenance mode.
• Pressing the [Stop/Exit] button after entering only one digit restores the machine to
the initial stage of the maintenance mode.
• If an invalid function code is entered, the machine resumes the initial stage of the
maintenance mode.
