1. OVERVIEW
Fig. 2-1
Control Section
Centronics
parallel interface
(CCD model only)
USB interface
Host Computer USB Memory
Control
panel
LAN
interface
USB Host
interface
Printer
data
Fax data
Low- and
high-voltage
power
supplies
AC
LAN
(For the models with the LAN only)
WLAN
PCB
For the model with the
wireless LAN only
Paper
feeding
mechanism
Laser printing unit
*Provided on models supporting facsimile function.
Charging, exposing,
developing,
transferring, and
heat-fixing processes
- Electrical charger
- Laser unit
(including the polygon
motor)
- Laser-sensitive drum
- Developer roller
- Transfer roller
- Heater roller
- Main motor
Scanner unitADF unitNCU*Line Speaker
- Scanner module
- Scanner motor
- ADF
motor
