5-176
Confidential
9.18.3
Pull Arm Guide
(1) Remove the two Lock claws, and remove the two Pull arm guides from the Joint cover
ASSY.
Fig. 5-205
Pull arm guide
Lock claw
Pull arm guide
Lock claw
