Brother MFC-8480DN Service Manual

7-25
Confidential
4.11 PC Print Function (Function code 43)
<Function>
This function allows the machine change that the setting of each PC printing function
indicated to the following function settings.
<Operating Procedure>
(1) Press the [4] and [3] keys in this order in the initial stage of the maintenance mode.
The “Manual Feed” will appear on the LCD.
(2) Press the [ ] or [ ] buttons to select the function you want to set and press the [OK]
button.
(3) When select the unchanging (On/Off) parameter, press the [ ] or [ ] button to change
the parameter, then press the [OK] button.
When select the parameter of the numeric input, enter the numeric value using the
numeric keys directly, then press the [OK] button.
(4) If press the [Stop/Exit] button, the machine will return to the initial stage of the
maintenance mode.
■ Function setting
LCD indication Description Set value
Initial
value
Manual Feed Switching of the Manual Feed On/Off Off
Resolution Resolution to print 300/600/1200dpi 600
Toner Save Switching of the Toner Save On/Off Off
Density Switching of the Density level -6 to 6 0
JB-Can Time Setting of the time until the host
time-out at the Job Cancel
2 to 225 (seconds)
4
Sleep Time Setting of the time until enter the
Sleep Mode
0 to 99 (minutes)
5
Page
Protection
Switching of the protection of the
page memory
Off/Letter/A4/Legal/Auto
Off
Emulation Switching of the emulation Auto/HP/PS Auto
Auto I/F Time Switching of the I/F open time 1 to 99 (seconds) 5
Media Type Switching of the recording paper
type
Thin/Plain/Thick/Thicker/
Trancparency/Recycled/
Bond/Envlopes/EnvThin/
EnvThick
Plain
or
Thin
Paper Size Switching of the area of develop the
Letter/Legal/A4/
Executive/B5/JISB5/A5/
B6/A6/Monarch/C5/
COM10/DL/DLL/
A4Long/PostCard/Folio
Letter
or
A4
Copies Switching of the print copies 1 to 99 (pages) 1
Orientation Switching of the print direction PortLait/Landscape Portlait
P-Pos X-Offset Switching of the offset print position
of the landscape orientation
-500 to 500 (1/300dpi)
0
P-Pos Y-Offset Switching of the offset print position
of the portrait orientation
-500 to 500 (1/300dpi)
0

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
