Brother MFC-8480DN Service Manual

3-45
Confidential
4.7 Curl in the paper
Slide the tab 2 to the right while pushing up the tab 1 to the direction of the arrow.
Fig. 3-4
4.8 Prints only single side of the paper when duplex-printing
The curl in the left figure.
<User Check>
- Change the paper.
Step Cause Check
Result Remedy
1
Mismatch the
setting the paper
and the eject roller
1
Is the problem solved by
changing the position of
the anti-curl switch?
Yes
Change the position of the
anti-curl switch.
<User Check>
- Use the paper only for A4 or letter size.
Tab 2
Anti-curl switch
Tab 1
