Brother MFC-8480DN Service Manual

7-3
Confidential
3. USER-ACCESS TO THE MAINTENANCE MODE
Basically, the maintenance-mode functions listed on the previous page should be accessed
by service personnel only. However, you can allow end users to access some of these under
the guidance of service personnel (e.g., by telephone).
The user-accessible functions (codes 06, 09, 10, 11, 12, 25, 43, 45, 53, 54, 77, 80, 82, 87, 88
and 91) are shaded in the table given on the previous page. Function code 10 accesses the
firmware switches, each of which has eight selectors. You should not allow end users to
access all of those selectors, but you can allow them to access user-accessible selectors
which are shaded in the firmware switch tables in APPENDIX 1.
The service personnel should instruct end users to follow the procedure given below.
(1) Press the [Menu], [Start], [Menu], and [ ] buttons in this order.
The "MAINTENANCE 10" appears on the LCD.
(2) Press the [ ] button or [ ] button several times to display the desired maintenance
code on the LCD.
Then press the [OK] button.
(3) To switch the machine back to the standby state, press the [Stop/Exit] button. When
each of the user-accessible functions is completed, the machine automatically returns to
the standby state.

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
