Brother MFC-8480DN Service Manual

3-25
Confidential
■ Error code 88
Paper jam inside the machine
■ Error code 89
Incorrect paper size in duplex printing
Jam Inside
Open the Front Cover, pull out the Drum Unit completely and remove
the jammed paper.
<User Check>
• Check if the paper is jammed around the removed drum unit. If jammed, remove it.
Step Cause Remedy
1
Harness connection failure of high
voltage power supply PCB ASSY.
Check the harness connection of the high
voltage power supply PCB ASSY and
reconnect it.
2
Registration rear actuator catching
on some position
Correct catching of the registration rear
actuator.
3
Registration rear sensor failure Check the sensor performance following
the procedure described in “Maintenance
mode 32”. If any problem occurs, replace
the high voltage power supply PCB ASSY.
4 Main PCB failure Replace the main PCB ASSY.
Check Paper size
Reload correct paper.
<User Check>
• Use the A4 size or letter size paper.
Step Cause Remedy
1
Registration rear sensor failure Check the sensor performance following
the procedure described in “Maintenance
mode 32”. If any problem occurs, replace
the high voltage power supply PCB ASSY.
2 Main PCB failure Replace the main PCB ASSY.

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
