Brother MFC-8480DN Service Manual

7-26
Confidential
■ Detail description
AutoFF Switching of the auto form feed On/Off Off
AutoFF Time Switching of the time-out period of
the auto feed
1 to 99 (seconds)
5
FF Surpress Switching of the FF suppress On/Off Off
Auto LF Switching of the auto LF On/Off Off
Auto CR Switching of the auto CR On/Off Off
Auto WRAP Switching of the auto CRLF at the
print width
On/Off
Off
Auto SKIP Switching of the SKIP at the back-
end/tip of the recording paper
On/Off
On
Left Margin Switching of the margin at the left
end
0 to 145 (columus)
0
Right Margin Switching of the margin at the right
end
10 to 155 (columus)
80
Top Margin Switching of the margin at the upper
end
0 to 2.00 (inches)
0.5
Bottom Margin Switching of the margin at the
bottom end
0 to 2.00 (inches)
0.5
Lines Number of the text lines in the page 5 to 128 (lines) 60
Error Print Switching of the Error Print of the
Post Script
On/Off
On
LCD indication Detail description
Manual Feed Effective for the print from the PC, or for the print of the NetWorkConfig/
TestPrint/Fontlist/Configuration from the panel. When select the tray on
the PC, the setting becomes effective. And this setting is ignored.
Resolution Effective only for the print from the PC. When set the Resolution on the
PC, the setting becomes effective. And this setting is ignored.
Toner Save Effective for all print, and change the setting of the Function Menu.
However, as for the Copy, this setting becomes invalid. When set the
Toner Save or the PC, the setting becomes effective. And this setting is
ignored.
Density Effective for the print from the PC, or for the print of the NetWorkConfig/
TestPrint/FontList/Configuration from the panel. Link the setting of the
Toner Save. Judge the both setting, and decide the density. When set
the Density or the PC, the setting becomes effective. And this setting is
ignored.
JB-Can Time Configure the setting for until the host time-out at the Job Cancel.
The setting value is the second time scale.
Sleep Time Configure the setting for the time until shift to the Sleep Time. Change
the setting of the Function Menu.
Page
Protection
Configure the setting to protect the page memory, when recording in PC.
Set in the PCL-Core. There is not the influence of the memory
management problem of the MFC.
Emulation Configure the setting for the Emulation. Charge the setting of the
Function Menu. When the data include the ENTER LANGUAGE, the
setting becomes effective. And this setting is ignored.
LCD indication Description Set value
Initial
value

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
