Brother MFC-8480DN Service Manual

3-69
Confidential
(11) General communications-related
(12) Transmission in V. 34 mode
Code 1 Code 2 Causes
B0 02 Unable to receive the next-page data.
B0 03
Unable to receive polling even during turn-around
transmission due to call reservation.
B0 04 PC interface error.
BF 01
Communication canceled by pressing the Stop/Exit
button before establishment of FAX communication*.
BF 02
Communication canceled by pressing the Stop/Exit
button after establishment of FAX communication*.
BF 03
Transmission canceled due to a scanning error caused
by no document or document feed problem in ADF
scanning in real time transmission.
* Establishment of FAX communication:
FAX communication is established when the calling station receives a DIS
(reception capability) signal from the called station and the called station receives a
NSS or DCS (communications test) signal from the calling station.
Code 1 Code 2 Causes
C0 01 No common modulation mode or failed to poll.
C0 02 Unable to detect JM.
C0 03 Unable to detect CM.
C0 04 Unable to detect CJ.
C0 10 Cannot finish V. 34 negotiation or training.
C0 11
Modem error is detected during V. 34 negotiation or
training. (For modem error details, refer to the table
given on the next page.)
C0 20
Modem error is detected during sending of commands.
(For modem error details, refer to the table given on the
next page.)
C0 21
Modem error is detected during receiving of commands.
(For modem error details, refer to the table given on the
next page.)
C0 22 Control channel connection time-out.
C0 30
Modem error is detected during sending of video
signals. (For modem error details, refer to the table
given on the next page.)
C0 31
Modem error is detected during receiving of video
signals. (For modem error details, refer to the table
given on the next page.)

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
