Brother MFC-8480DN Service Manual

1-3
Confidential
Specifications are subject to change without notice.
Model DCP8070D MFC8370DN MFC8380DN
Print method
Electrophotography by semiconductor laser beam scanning
Laser Method: 1 polygon motor, 1 laser beam
Wavelength: 770 nm - 810 nm
Output: 5 mW (Max)
Laser class: Class3 B
Resolution
1200 dpi
*1
,
HQ1200
(2400x600dpi)
Windows
®
2000/XP/ XP Professional x64 Edition, Windows
Vista
®
, Windows Server
®
2003/ Windows Server
®
2003 x
64 Edition, Windows Server
®
2008, Mac OS
®
X 10.3.9 or
greater, Linux
600 x 600 dpi
Windows
®
2000/XP/ XP Professional x64 Edition, Windows
Vista
®
, Windows Server
®
2003/ Windows Server
®
2003 x
64 Edition, Windows Server
®
2008, Mac OS
®
X 10.2.4 or
greater, DOS, Linux
Print mode Normal printing mode
Economy printing mode (Toner saving mode)
Print Speed
(A4/Letter)
Standard Up to 28 ppm
* When loading
A4 or Letter-
size paper from
the standard
paper tray.
Up to 28 ppm
* When loading
A4-size paper
from the
standard paper
tray.
Up to 30 ppm
* When loading
A4-size paper
from the
standard paper
tray.
Duplex Up to 13 sides per
minute
(6.5 sheets per
minute) (A4)
Up to 13 sides per minute
(6.5 sheets per minute) (A4)
Warm-up time
*2
From sleep mode: less than 18 seconds
From power off
→ on: less than 35 seconds
First print time
*3
Less than 8.5 seconds

Brother MFC-8480DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Print speed (black, normal quality, A4/US Letter)	32 ppm
Grayscale levels	256
Input color depth	48 bit
Image formats supported	BMP, JPG, TIF
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Copier resize	25 - 400 %
Maximum number of copies	99 copies
Copy speed (black, normal quality, A4)	32 cpm
Faxing	Mono faxing
Fax memory	600 pages
Modem speed	33.6 Kbit/s
Power supply type	AC
Weight (imperial)	40.3 lbs
Dimensions (WxDxH)	530.8 x 449.5 x 474.9 mm
Power requirements	110 - 240V, 50/60 Hz
All-in-one functions	Copy, Fax, Scan
Standard media sizes	2.75'' - 8.5\
Maximum internal memory	0.576 GB
Color all-in-one functions	scan, n
Compatible operating systems	Windows OS Mac OS
Package dimensions (W x D x H)	24.7 x 22.3 x 22.6 \
Total input capacity	250 sheets
Total output capacity	150 sheets
Auto document feeder (ADF) input capacity	50 sheets
Display	LCD
Market positioning	Business
Internal memory	64 MB
Sound pressure level (copying)	56 dB
Sound pressure level (printing)	30 dB
Maximum print size	216 x 356 mm
Paper tray media types	Bond paper, Envelopes, Plain paper, Recycled paper, Transparencies
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Supported network protocols (IPv4)	ARP, RARP, BOOTP, DHCP, APIPA, LLMNR, LPR/LPD, IPP/IPPS, FTP, HTTP/HTTPS, SSL/TLS, TFTP, SMTP, APOP, POP, SMTP, SMTP-AUTH, SNMPv1/v2c/v3, ICMP, LLTD, CIFS, SNTP, NDP, RA, DNS, mDNS, ICMPv6
Standard interfaces	USB 2.0
USB 2.0 ports quantity	1
Power consumption (standby)	18 W
Power consumption (average operating)	680 W
Package weight	21645 g
Sustainability certificates	ENERGY STAR
Maximum duty cycle	30000 pages per month
Recommended duty cycle	3500 pages per month
Operating temperature (T-T)	10 - 32.2 °C
Operating relative humidity (H-H)	20 - 80 %
