4-62
Confidential
(2) Assemble the Lift arm onto the Pin of the Roller holder ASSY.
(3) Place the machine on its base.
Fig. 4-94
2a
Lift arm
Pin
Roller holder ASSY
Paper feed frame
2b2b
